Remote Desktop Client (or RDC), commonly known as Mstsc.exe main client program that uses Remote Desktop to connect to the service. RDC also use the console itself, through Group Policy configuration is highly significant.
In the Windows client, RDC, in fact, to remote servers and clients are no longer being used. To view the menu and configure it the way you start, All Programs, Accessories and Remote Desktop Connection to run it. Also Mstc by typing in Run, the program will be implemented. The following figure shows the Remote Desktop Connection.
To access the settings, you need to click Options (bottom left) button. In this section, you will get 6 tabs:
General normally when you open your console RDC, IP destination computer (the computer that you want to remote login) and connect into you after a while you have a Username and Password of computer request authentication to login. The forms, the target computer for remote this store will not need to type them again in the future reference. Note that when you get to a remote computer, you're in with a user name, as well as local person who is logged into the computer and use it. The only difference is that you're remote. So in the Computer, or should type the full name of the target computer (such as SERVER01.serversetup.ir), or you must type the IP..ir) After entering your username when you connect, you are asked for your password after you log remote.
If you change your username or delete, edit or delete, you can use (shown on the figure below)
If your destination is always a remote computer, you can use it as a shortcut icon (shortcut) that lets you double click on it in the future reference only and remote login. The solution for employees who every day is going to be remote server. To do this, from the Connection Settings click on Save As and choose a name for it and where to save it (file stored .rdp *).
Display This tab allows you to screen resolutions and color bit depth for the remote client (the system), determine. Remember, when you get to the remote computer, in fact, through the network (wired or wireless) desktop system you get on your monitor. Therefore, networks (cables, switches, network cards, etc.), number of concurrent users on remote systems, and hardware that are effective in image quality and speed of your work. So, you can use this tab, set the color quality of the display.
Local Resources In this tab you can choose which of your computer's hardware resources (such as Clipboard, local printers directly connected to your system and drive local) it used to be in session. You can also audio settings button on the Remote Audio Settings change. For recording, you can choose to record your voice through your own system or the microphone cut off. (Remote Audio Recording)
Also, the Keyboard, you can set that as the Alt + Tab key combination can be used in remote systems. For example, choose Only when using the full screen means that key combination can be used when the remote is not full screen.
In the local devices and resources can choose, for example, remote computer system Clipboard local printers are available.
Programs This tab allows you to connect remote when you start each application that you want to run automatically. To do so, simply uncheck the start the following program on connection to and enter the file path. Just keep in mind that this part, when you have server performance RD Session Host (the Terminal server) Remote login
Experience This tab enables you to some graphical (GUI) that you want on the target computer (remote) applied, choose. This option is for graphical issues when low performance network platform you are, whatever you want to remote graphics will lower more quickly. For example, features Desktop background and font-smoothing, the appearance RD session to increase the speed and reduce network. RDC detects when low performance network platform, to increase the efficiency of remote settings are automatically selected.
Advanced tab, you can treat the client to Server Authentication and Remote Desktop Gateway (or RD Gateway) manage. Server Authentication By default, the Remote Desktop Protocol 6.0 is a Vyzhgyst that there onwards, and in a way that RD Session Host server can authenticate the remote client going to the client to do the same. This makes the correct remote computer or server you want to connect.
The approved (server authentication) to communicate by a system security policy on the server you set is measured. If the authentication policy, at least not in the server authentication before you have three options:
Connect and don`t warn me With this option, if Remote Desktop Connection authentication do not, in any way connected.
Warn me With this option, if Remote Desktop Connection does not perform authentication, you will also notice that you want to connect or not.
Do not connect with the option, if Remote Desktop Connection Authentication is not not communicate.
In the Connect from anywhere can also configure RD Gateway. This feature allows you to have a RD client, from outside your network, all network firewalls passed to any number of servers in the RD Session Host connected. This section is part of the RD Gateway explained.
